Endoscope CameraEndoscope Camera Location 512hz Remote Transmitter,SYANSPAN Signal Sonde For Underground Pipe Inspection System

512 Hertz Frequency Sonde

LED Indicator & -4°F -130°F & Abrasion-proof

The 512 hz sonde locator transmits a 512 Hz signal that can be picked up with any compatible locator, allowing users to pinpoint the transmitter's position underground. The flashing LED indicates that sonde is transmitting. The maximum detection range of transmitter for underground pipe location is 25 feet in the air and 15 feet in cast iron (varies with ambient noise and interference).

• 512HZ Strong Signal

• 2 Replaceable Connectors

• Integrated Seamless Design

• Waterproof Material

Premium Material
This underground pipe locator is made of durable steel and consists of two 304 stainless steel adapters. It is waterproof and rustproof.



304 Stainless Steel Connectors
Two stainless steel adapters provided for attaching 512 hertz frequency sonde to drum machine or sectional cables to satisfy your different requirements with long-time service.

Universal Compatibility
The pvc pipe detector underground is able to transmit the signal to any 512HZ receiving equipment and allows you to locate the inspected area accurately.



512HZ Transmitter
You can attach our sonda to drain cleaning cable or a water jet hose to locate pipe underground with a depth up to 25 Feet due to its strong signals of 512HZ.




Versatile Usage
This utility locator solves the hard work of inspecting sewer lines, drains, wells, walls, machinery, HVAC ductwork, tanks, general building inspection.

Specifications

• Model: VV-S-512

• Product Weight: 0.22lb/102g

• Product Diam: 0.93''/23.5mm

• Product Length: 2.87''/73mm

• Working Temp: -4°F -130°F/-20°C-54°C

• Integrally Formed Body
  Considering the collision of the 512 locator in the pipeline, the seamless injection molding process is adopted to avoid damage.

Features & Details

• 512HZ Strong Signal: This sonde makes your pipeline detection quick and easy. Furthermore, it is capable of working with any 512hz receiver. A flashing LED indicates that rigid locator is transmitting signal.

• 2 Replaceable Connectors: These two adapters can attach the sonde locator to drum machine or sectional cables separately. So they provide versatility in locating underground pipe and line detection.

• Integrated Seamless Design: The drain locator adopts seamless injection molding process to achieve better shock resistance. Even if accidentally falling from a height, it will not be easily damaged.

• Waterproof Material: The sewer locator can effectively avoid oxidation, rust, and corrosion to prolong its service life through the abrasion-proof coating. Besides, this waterproof 512 Hz locator can work at optimal temperature -4°F -130°F/-20°C-54°C.

• Wide Application: The water line locator can be attached to a drain cleaning cable or a water jet hose to locate the remote transmitter in a line. So it can be installed at the end of a fiberglass push cable, duct rod, or sewer cable.

• Package Content

• 1 x 512 Hertz Frequency Sonde

• 1 x 8/5'' in Diam Adapter

• 1 x 1/4-20 Model Adapter
